ADC Control and Status Register B
Name:
ADCSRB
Offset:
0x1C
Reset:
0x00
Access:
-
Bit76543210
ADLARADTSn[2:0]
AccessR/WR/WR/WR/W
Reset0000

Bit 7 – ADLAR: Left Adjustment for ADC Result Readout

Left Adjustment for ADC Result Readout

The ADLAR bit affects the presentation of the ADC conversion result in the ADC Data Register. Write one to ADLAR to left adjust the result. Otherwise, the result is right adjusted. Changing the ADLAR bit will affect the ADC Data Register immediately, regardless of any ongoing conversions.

Bits 2:0 – ADTSn: ADC Auto Trigger Source [n = 2:0]

ADC Auto Trigger Source [n = 2:0]

If ADATE in ADCSRA is written to one, the value of these bits selects which source will trigger an ADC conversion. If ADATE is cleared, the ADTS[2:0] settings will have no effect. A conversion will be triggered by the rising edge of the selected Interrupt Flag. Note that switching from a trigger source that is cleared to a trigger source that is set, will generate a positive edge on the trigger signal. If ADEN in ADCSRA is set, this will start a conversion. Switching to Free Running mode (ADTS[2:0]=0) will not cause a trigger event, even if the ADC Interrupt Flag is set.

Table 1. ADC Auto Trigger Source Selection
ADTS[2:0] Trigger Source
000 Free Running mode
001 Analog Comparator
010 External Interrupt Request 0
011 Timer/Counter 0 Compare Match A
100 Timer/Counter 0 Overflow
101 Timer/Counter 0 Compare Match B
110 Pin Change Interrupt 0 Request
111 Timer/Counter 0 Capture Event
