MCU: 32bits AT32UC3A3256 (QFP144)
-
256 kBytes Flash
-
128 kBytes RAM
-
Up to 66 Mhz operations
-
Very low power consumption
-
-
RTC
-
QVGA display with up to 16-bit color depth plus PWM backlight control
-
USB (2.0 mini A-B receptacle)
-
Analog to Digital Converters: 8 configurable channels (8/10 bits)
-
Audio feature: External amplifier for ABDAC with headphone jack
-
QTouch and QWheel Sensors
-
4 LEDs
-
Atmel DataFlash (8 MBytes)
-
SDRAM (32 MBytes)
-
1 USART with flow control
-
JTAG connector
-
Nexus connector
-
2 SD/MMC slot (1 4-bit data and 1 8-bit data)
-
1 SPI free lines
-
1 TWI free line
-
Powered through USB port or external
-
2 nand flash (2x 2Gbits)
-
1 Memory stick Duo Pro connector
-
1 CE-ATA 4-bit connector
